Description
Plastic check valves molded at our facility are made from NSF 51/62 Approved materials, used for food and beverage applications. Our valves do not have grease or oil, like other diaphragm valves on the market. Ideal for contact with Food, Beverage, Water and Laboratory applications. Housings are molded from materials include POM -Celcon, M90® and PVDF, Arkema-Kynar 720®. The diaphragm options are EPDM, Santoprene™, or FDA Viton® disks. Sizes we offer include 1/8, 3/16, 1/4, 5/16, and 3/8 barbed valves.
| Flow (l/h) | Crack Pressure | ||
|---|---|---|---|
| MPV-2B-AC-FDAViton | 1/8 Barbed Acetal with FDA Viton .020 | ||
| MPV-2B-AC-S | 1/8 Barbed Acetal with Santoprene | ||
| MPV-2B-AC-E | 1/8 Barbed Acetal with EPDM | 50.79 | .007 |
| MPV-3B-AC-FDA Viton | 3/16 Barbed Acetal with FDA Viton .020 | ||
| MPV-3B-AC-S | 3/16 Barbed Acetal with Santoprene | ||
| MPV-3B-AC-E | 3/16 Barbed Acetal with EPDM | 50.79 | .007 |
| MPV-4BH-AC-FDA Viton | 1/4 Barbed, Acetal, High Flow with FDA Viton .030 | ||
| MPV-4BH-AC-S | 1/4 Barbed Acetal,High Flow with Santoprene | ||
| MPV-4BH-AC-E | 1/4 Barbed Acetal,High Flow with EPDM | 26.28 | .001 |
| MPV-5B-AC-FDA Viton | 5/16 Barbed, Acetal, High Flow with FDA Viton .030 | ||
| MPV-5B-AC-S | 5/16 Barbed, Acetal, High Flow with Santoprene .030 | ||
| MPV-5B-AC-E | 5/16 Barbed, Acetal, High Flow with EPDM .030 | 26.28 | .001 |
| MBV-6B-AC-FDA Viton | 3/8 Barbed, Acetal, High Flow with FDA Viton .030 | ||
| MBV-6B-AC-S | 3/8 Barbed, Acetal, High Flow with Santoprene .030 | ||
| MBV-6B-AC-E | 3/8 Barbed, Acetal, High Flow with EPDM .030 | 26.28 | .001 |
