Description

The SSWS Series is a Brass Swivel Adapter. It is available with male NPT threads to female NPT threads or a barb connection. The working pressure for both the threaded and barbed swivels is 300 psi. Both swivels have a bronze thrust bearing and EPDM or FKM seals. This swivel provides a full 360° rotation. The barbs are intended to be used with a hose clamp.




SKUDESCRIPTION
SSWS-4M4B 1/4 MNPT by 1/4 Barb Brass Swivel
SSWS-6M6B3/8 MNPT by 3/8 Barb Brass Swivel
SSWS-8F8M1/8 FNPT by 1/8 MNPT Brass Swivel
SSWS-4F4M1/4 FNPT by 1/4 MNPT Brass Swivel
SSWS-6F6M3/8 FNPT by 3/8 MNPT Brass Swivel
